Rubber Conveyor Belts - Sidewall

Gemini_Generated_Image_nja3tnja3tnja3tn Topaz Gigapixel 2x scale.png

Sidewall rubber conveyor belt systems provide a compact, high-reliability solution for steep and vertical conveying up to 90°. Unlike conventional inclined conveyors requiring longer lengths and multiple transfer points, they minimise footprint, reduce spillage, and maintain efficient material flow across all stages.

​

Leopard Intertrade’s sidewall rubber conveyor belt integrates a cross-rigid base belt for lateral stability, reinforced cleats for secure retention, and corrugated sidewalls for full containment and durability. This ensures continuous, high-capacity handling of fine or coarse materials in demanding applications.

Cross-Rigid Base Belt

XE

Cross-rigid ply integrated into the carcass, providing balanced lateral stability and flexibility for reliable performance in medium-duty applications.

XE+2

Separate tension and dual cross-rigid plies improve lateral stiffness and load stability, suitable for medium- to heavy-duty conveying conditions.

XE-SC+2

Textile tension plies combined with steelcord cross-rigid members deliver high lateral rigidity, ideal for wide belts and higher lift applications.

Steelcord reinforcement in both tension and cross-rigid layers, for maximum strength, minimal elongation, and superior conveying stability.

Base Belt Specifications

Base Belt Type
Strength (N/mm)
Number of Plies
Top Cover Thickness (mm)
Bottom Cover Thickness (mm)
Weight (kg/m²)
Min. Pulley Ø (mm)
XE
250
2
2
2
9.4
200
XE
400
3
4
2
13.5
315
XE
500
3
4
2
13.75
400
XE
630
4
4
2
15.2
500
XE
800
5
4
2
16.85
630
XE+2
400
3+2
4
2
12.1
315
XE+2
500
3+2
4
2
12.6
400
XE+2
630
4+2
4
2
14.4
500
Page 1 of 1

Sidewall Range

Sidewall Type
H (mm)
SW (mm)
TW (mm)
P (mm)
Weight (kg/m)
Min. Pulley Ø (mm)
S
40
30
30
42
0.52
125
S
60
50
45
42
1.36
160
S
80
50
45
42
1.6
200
S
100
50
45
42
2.05
250
S
120
50
45
42
2.46
315
HDS
120
75
70
63.5
4.5
315
HDS
160
75
70
58.5
5.65
400
HDS
200
75
70
58.5
6.28
500
HDS
250
75
70
58.5
8.35
630
HDS
280
75
70
58.5
9.03
800
HDS
300
75
70
63.5
9.07
800
XHDS
300
100
90
83
10.1
800
XHDS
400
100
90
83
13.43
1000
XHDS
500
100
90
83
20
1250
XHDS
630
100
90
83
24
1600

S and HDS types are available in both fabric-reinforced and non-reinforced options.

XHDS type is available in fabric-reinforced only.

Screenshot 2569-05-10 at 13.32.37.png

Our sidewalls are engineered to deliver optimal vertical flexibility while maintaining superior lateral strength. Fabric reinforcement improves tear resistance, tensile durability, and mounting stability under demanding operating conditions.

​

Available in S, HDS, and XHDS profiles, with both reinforced and non-reinforced configurations. Diagonal reinforcement minimises stress cracking and enhances foldability along the return path.

Cleat Range

Cleat Type
Height (mm)
Base Width (mm)
Weight (kg/m)
Min. Pulley Ø (mm)
Production Length (m)
C
35
55
0.5
100
3/5
C
55
75
1.5
125
3/5
C
75
80
2
150
3/5
C
90
110
2.3
250
3/5
C
110
110
2.5
315
3/5
TC
75
80
1.8
150
3/5
TC
90
110
2.5
250
3/5
TC
110
110
2.8
315
3/5
TC
140
160
6.6
400
2.5
TC
180
160
8.3
500
2.5
TC
230
175
10.46
630
2.5
MBTC
110
160
7.9
315
3
Page 1 of 1

The pulley diameters provided are based on standard belt quality and cover thickness. For belts with specialised cover grades or differing tensile ratings, please contact us for guidance, as larger pulley diameters may be required.

Our cleats are moulded from durable rubber compounds engineered for excellent wear resistance, shape retention, and self-cleaning performance. Suitable for conveying angles up to 90° (depending on cleat type), they are available in eight different types and can be hot-vulcanised or mechanically fastened for easier maintenance.
